The Estate Series from Concord American Flagpole provides commercial grade flagpoles that are a perfect fit for budget minded projects. Manufactured to the same quality standards as our Continental Series, our Estate Series offers flagpoles with heights from 15′ to 35′ which are ideal for residential homes, small businesses and commercial complexes.
- Rope Halyard - 5/16" #10 Polyester
- Two (2) Nickle Plated Cast Zinc Swivel Flagsnaps
- Two (2) Neoprene Flagsnap Covers
-9" Cast Aluminum Cleat
Shoe Base Designs for Surface Mount Installations are available in 4" and 5" Estate Series – ESS Flagpoles.
4"-5" Butt Diameters Add $246
Residential Stationary Beacon
Rope Halyard - Cap Style Truck
Flagpole Lighting Options are available for all Estate Series Flagpoles
| Mtg Hgt. | Butt Dia. | Wall Thickness | Pole Sections | Set Depth | Top Diam. | Std Flag Size | Max Wind Speed With Nylon Flag | Max Wind Speed No Flag | Catalog Number ***Specify Finish | Satin | Clear Anodized | Dark Bronze or Black Anodized | Bronze Tone, Black, White, or Clear Powdercoat |
| 15' | 3" | .125" | 1 | 2'-0" | 2" | 3' x 5' | 113 | 149 | ESS15B31-*** | $608 | $747 | $785 | $752 |
| 20' | 3" | .125" | 1 | 2'-0" | 2" | 4' x 6' | 83 | 108 | ESS20B31-*** | $710 | $879 | $927 | $896 |
| 4" | .125" | 1 | 2'-0" | 3" | 4' x 6' | 109 | 147 | ESS20B41-*** | $1065 | $1,307 | $1,370 | $1,264 | |
| 5" | .125" | 1 | 2'-0" | 3" | 4' x 6' | 136 | 229 | ESS20B51-*** | $1,326 | $1,628 | $1,706 | $1,609 | |
| 5" | .156" | 1 | 2'-0" | 3" | 4' x 6' | 160 | 262 | ESS20C51-*** | $1,476 | $1,801 | $1,879 | $1,759 | |
| 5" | .188" | 1 | 2'-0" | 3" | 4' x 6' | 182 | 287 | ESS20D51-*** | $1,732 | $2,095 | $2,174 | $2,016 | |
| 25' | 3" | .125" | 1 | 2'-6" | 2" | 5' x 8' | 63 | 83 | ESS25B31-*** | $849 | $1,052 | $1,110 | $1,075 |
| 4" | .125" | 1 | 2'-6" | 3" | 5' x 8' | 83 | 106 | ESS25B41-*** | $1,181 | $1,457 | $1,533 | $1,421 | |
| 5" | .125" | 1 | 2'-6" | 3" | 5' x 8' | 98 | 136 | ESS25B51-*** | $1,549 | $1,906 | $2,001 | $1,892 | |
| 5" | .156" | 1 | 2'-6" | 3" | 5' x 8' | 111 | 178 | ESS25C51-*** | $1,825 | $2,223 | $2,318 | $2,167 | |
| 5" | .188" | 1 | 2'-6" | 3" | 5' x 8' | 124 | 209 | ESS25D51-*** | $2,300 | $2,770 | $2,865 | $2,643 | |
| 30' | 4" | .125" | 1 | 3'-0" | 2" | 6' x 10' | 66 | 85 | ESS30B41-*** | $1,485 | $1,831 | $1,925 | $1,783 |
| 4" | .125" | 2 | 3'-0" | 2" | 6' x 10' | 66 | 85 | ESS30B42-*** | $1,534 | $1,887 | $1,981 | $1,831 | |
| 5" | .125" | 1 | 3'-0" | 3" | 6' x 10' | 78 | 96 | ESS30B51-*** | $1,709 | $2,120 | $2,238 | $2,134 | |
| 5" | .125" | 2 | 3'-0" | 3" | 6' x 10' | 78 | 96 | ESS30B52-*** | $1,860 | $2,294 | $2,412 | $2,286 | |
| 5" | .156" | 1 | 3'-0" | 3" | 6' x 10' | 86 | 112 | ESS30C51-*** | $2,093 | $2,562 | $2,680 | $2,518 | |
| 5" | .156" | 2 | 3'-0" | 3" | 6' x 10' | 86 | 112 | ESS30C52-*** | $2,165 | $2,645 | $2,762 | $2,590 | |
| 5" | .188" | 1 | 3'-0" | 3" | 6' x 10' | 94 | 131 | ESS30D51-*** | $2,413 | $2,930 | $3,048 | $2,838 | |
| 5" | .188" | 2 | 3'-0" | 3" | 6' x 10' | 94 | 131 | ESS30D52-*** | $2,485 | $3,012 | $3,130 | $2,910 | |
| 35' | 5" | .156" | 1 | 3'-6" | 3" | 6' x 10' | 73 | 87 | ESS35C51-*** | $2,161 | $2,666 | $2,803 | $2,657 |
| 5" | .156" | 2 | 3'-6" | 3" | 6' x 10' | 73 | 87 | ESS35C52-*** | $2,201 | $2,712 | $2,849 | $2,697 | |
| 5" | .188" | 1 | 3'-6" | 3" | 6' x 10' | 79 | 95 | ESS35D51-*** | $2,627 | $3,202 | $3,339 | $3,123 | |
| 5" | .188" | 2 | 3'-6" | 3" | 6' x 10' | 79 | 95 | ESS35D52-*** | $2,839 | $3,445 | $3,583 | $3,335 |
Cap Mounted Style Single Revolving Truck In Lieu Of Standard Stationary Truck. –Add $67
Cast Aluminum FC-11 Collar In Lieu of Spun Collar –
3″-5″ Butt Diameters ……… Add $67
Cleat Cover (Specify Cylinder Lock or Padlock) – See Page 77. 3″-4″ Butt Diameters…….. Add $128 5″ Butt Diameters ………. Add $158
Cleat Cover Box with 5′ Halyard Cover (Specify Cylinder Lock or Padlock) – See Page 77. 3″-4″ Butt Diameters ……. Add $243 5″ Butt Diameters ………. Add $305
SAT = Satin
ACL = Anodized - Clear
ADB = Anodized - Dark Bronze
ABL = Anodized - Black
BZT = Powder Coat - Bronze Tone
BLK = Powder Coat - Black
WHT = Powder Coat - White
CLR = Powder Coat - Clear
5+ = 5% 8+ = 10% 15+ = 12% * Flagpoles From All Flagpole Series May Be Combined To Achieve Quantity Discounts.
